Product imageMolicel INR-21700-P50S is a 21700 Safety Cell with 5000mAh typical capacity and 3.6V nominal voltage. The manufacturer data sheet lists 60A standard discharge and 100A maximum discharge with an 83°C cut-off for BBU and data-center battery projects.
Molicel INR-21700-P50S is a 21700 Safety Cell with 5000mAh typical capacity and 3.6V nominal voltage. The manufacturer data sheet lists 60A standard discharge and 100A maximum discharge with an 83°C cut-off for BBU and data-center battery projects.
5000mAh, 71g
60A, 100A, 83℃
260Wh/kg · 714Wh/L
5A standard · 25A maximum · 83°C cut-off
Review the specifications and operating conditions below. Confirm the applicable manufacturer data sheet before final design or procurement.
Evaluate continuous and peak demand, parallel strings, BMS limits, voltage drop, thermal rise and runtime requirements at pack level.
Evaluate redundancy design, rack-level monitoring, thermal behavior and required compliance evidence for the intended backup architecture.
Confirm cell count, interconnect resistance, protection thresholds, ventilation and validation under the project duty cycle.
Please provide the full model, application, expected quantity, project stage and destination so we can confirm product and supply information.
