Panasonic / Sanyo UR18650ZY
⚡3.7V 5A 🔋2600mAh
📌 UR18650ZY Overview
Panasonic / Sanyo UR18650ZY is an 18650 cylindrical rechargeable lithium-ion cell with 2600mAh typical capacity, 3.7V nominal voltage, and 5A maximum continuous discharge current, designed for economical low-drain consumer and general-purpose applications.
UR18650ZY is suitable for budget power banks, desktop fans, standard flashlights, small home appliances, instrument backup power, access control backup systems, and simple low-power IoT devices requiring stable runtime and cost-effective battery pack design.
✨ UR18650ZY Key Features
● 🔋 Format: 18650 cylindrical cell with 2600mAh typical capacity and 48g max weight
● ⚡ Positioning: economical low-drain consumer cell focused on stable runtime, cost efficiency, and broad compatibility, with 5A continuous discharge capability
● 📊 Application Profile: suitable for low-power, low-current, and long-runtime applications in consumer electronics, small appliances, and basic backup power systems
● 🔌 Charging: 1.75A standard charge current for general consumer battery packs and low-power device applications
● 🌡️ Temperature Range: charge temperature from 0℃ to +45℃ and discharge temperature from -20℃ to +60℃ for general indoor and outdoor low-power applications
● 🔁 Stability: stable discharge platform and basic cycle performance for battery pack projects requiring cost control, runtime, and reliable power delivery
🛠️ UR18650ZY Applications
🔋 Budget Power Banks
Suitable for budget power banks, basic mobile power supplies, and compact backup power systems.
🌀 Desktop Fans / Portable Humidifiers
Designed for desktop fans, portable humidifiers, and low-power small home appliances requiring stable continuous power.
🔦 Standard Flashlights
Can be used in standard flashlights, portable lighting, and low-to-medium-power lighting devices.
🧸 Small Handheld Electric Toys
Suitable for small handheld electric toys, low-power entertainment devices, and compact consumer electronics.
🏭 Instrument Backup Power
Suitable for general instruments, meters, testing devices, and low-power industrial or civil backup power applications.
🚪 Access Control Backup Power
Can be used in access control systems, security devices, and low-power backup power modules.
📡 Simple Low-Power IoT Devices
Suitable for simple IoT devices, sensors, and low-power wireless terminals requiring embedded power solutions.
📊 UR18650ZY Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Panasonic / Sanyo |
| Model | UR18650ZY |
| Cell Format | 18650 |
| Form | Cylindrical |
| Cell Type | Rechargeable lithium-ion cell |
| Series | Economical General-Purpose 18650 Consumer Series |
| Typical Capacity | 2600mAh |
| Minimum Capacity | 2500mAh |
| Rated Capacity | 2450mAh |
| Nominal Voltage | 3.7V |
| Max Continuous Discharge Current | 5A |
| Standard Charge Current | 1.75A |
| Max Charge Voltage | 4.20V |
| Discharge Cut-off Voltage | 2.75V |
| Standard Charge Time | 3.0h |
| Charge Temperature | 0℃ to +45℃ |
| Discharge Temperature | -20℃ to +60℃ |
| Approx. Weight | 48g max |
| Positioning | Economical low-drain consumer 18650 cell |
| Key Characteristics | Cost-effective, stable runtime, low-drain general-purpose power, suitable for small-power devices |
| Applications | Power banks, small fans, standard flashlights, small appliances, instrument backup power, access control backup power, low-power IoT devices |
